Machine type 1007
Freely programmable 4-fold automatic belt riveter
Freely programmable 4-fold automatic belt riveter for the automatic insertion of four different self-piercing rivets in a single operation. The rivets are fed and pressed in automatically via a vibration conveyor. All rivets are set automatically. The riveting units can be switched on or off individually via the control panel. Equipped with a quick-change device for the rivet feeders and tools. The pressure setting of the rivets is made via an adjusting screw on the lower tool. The X and Y axes can be programmed via a graphics program. The insertion device for the leather goods is always centered. With protective housing, electric foot switch and piece counter.
Technical specifications
- Control panel with PLC control and operating panel
- Sorting drum drive: Electric with minimum and maximum control and rivet fall-through detection
- Output: 120 cycles/minute
- Drive: Servo motor
- Sorting drive: Vibratory conveyor
- Cycle feed: Stepper motors
- Insertion device. Belt width up to 60 mm
- Working height: approx. 1000 mm
- Weight: approx. 300 kg
- Space requirement: 1200 x 2500 x 1750 mm
- Air pressure: approx. 6 bar
- Projection: 200 mm freely cantilevered
Examples of use
- Belt industry
- fashion accessories
- Dog collars
- Dog leashes
- etc.
